AusRamp 5-Tonne 3.5m x 550mm Aluminium Loading Ramps
Authorised dealerSKU: 5-510SR$2,723.64 ex GST
- Length3500mm
- Holds5,000kg
- Weight49kg (per ramp)
- Made ofAluminium
- Suited to tracked and wheeled machines
- Australian designed and manufactured
- Connecting plate and pin ensures maximum stability and safety
Will it reach your deck? Reaches 1200 mm. Check yours›
Reaches a deck up to 1200 mm high, as rated by AusRamp.
Open the ramp calculatorAvailable to order, ships within 1-2 weeks
Authorised dealeri
200+ soldi
Pickup availablei
12-month warrantyi
Made in Australiai
Rated 4.7 from 1,186 reviews on Google, ProductReview and Trustpilot
Goes well with
AusRamp 5-Tonne 3.5m x 550mm Aluminium Loading Ramps
Loading ramp specifications and dimensions
| Holds | 5,000kg |
|---|---|
| Made of | Aluminium |
| Colour | Silver |
| Brand | AusRamp |
| SKU | 5-510SR |
| Length | 3500mm |
| Width | 550mm |
| Height | Up to 1200mm |
| Weight | 49kg (per ramp) |
| Dimensions | L x W x H 3500mm x 560mm x 370mm |
| Internal width | 470mm |
| Depth | 150mm |
About this loading ramp
Made in Australia for strong, safe machine loading
The AusRamp 5 Tonne 3.5m x 550mm Aluminium Machinery Loading Ramps are over-engineered to ensure they can safely accept steel or rubber tracks and pneumatic tyres.
This means you no longer need to have individual ramps to cope with various means of traction. One set of AusRamp loading ramps does it all.
At a capacity rating of 5 tonnes per pair, the lightweight aluminium ramps are ideal for loading agricultural industry machines, tractors, skid steers and mini excavators.
AusRamp ramps incorporate a design feature that prevents bottoming out when loading or unloading.
Additionally, all ramps are supplied with forged locking pins to ensure a safe, secure attachment to the loading plate.
Can't find the ramp you're looking for? Use the chat function in the corner of the window or Contact us for advice if you're unsure what ramps are suitable for you.
Key benefits
- Suited to tracked and wheeled machines
- Australian designed and manufactured
- Manufactured from structural-grade alloys to ensure the maximum strength available
- Compliance Plates recording the model number, load capacity and serial number ensure traceability and safe work practice
- Connecting plate and pin ensures maximum stability and safety
- 12-month warranty
- Sold in pairs
Delivery
Delivery
This product is a "Bulky Item". Delivery to a business address with unloading facilities or depot is recommended.
Estimate delivery to your door
An estimate for this item to that suburb, from the same rates checkout uses. You choose the delivery method at checkout.
Finance Options
Finance Options
Four interest-free payments, the first at checkout. Choose PayPal at checkout and pick Pay in 4.
How Pay in 4 works on PayPal3 months interest-free. Choose Zip at checkout. Fees, T&Cs and credit approval apply.
How Zip works on zip.co
Orders over $10,000Equipment financeBusiness equipment finance through Centrepoint Finance. Talk to their team about your purchase.
Apply with Centrepoint
Request a Quote
Request a Quote
Loading ramp downloads
Everything you need to plan, install and use it. Free to download.
Need another document or a different format? Ask us
Reviews
FAQs
Will these ramps take my machine?
Will these ramps take my machine?
AusRamp rate every model for the pair, not each ramp. Add up the machine, its attachments and the operator, and pick a pair rated above that total.
Is the price for one ramp or a pair?
Is the price for one ramp or a pair?
The price is for a pair. The weight shown in the Specifications is per ramp.
How do they attach to my truck or trailer?
How do they attach to my truck or trailer?
With a connection plate on your truck or trailer and a pin through each ramp, so they lock on with a positive connection rather than just resting on the deck.
How high a deck will they reach?
How high a deck will they reach?
AusRamp recommend these 3.5m ramps for loading heights up to 1.2m. They also make 3.9m ramps for decks up to 1.4m.
Can I load a machine on steel tracks?
Can I load a machine on steel tracks?
Yes. This is an AusRamp SR model, made for steel and rubber tracked machines.
Where are AusRamp ramps made?
Where are AusRamp ramps made?
In AusRamp's own workshops in Melbourne. They have been Australian made for over 30 years.
Warranty, returns, ordering and delivery
Warranty, returns, ordering and delivery
What is the warranty on AusRamp items?
What is the warranty on AusRamp items?
Ramp Champ only works with well-known, industry-leading manufacturers such as AusRamp. Every product comes with its manufacturer's warranty. The warranty badge next to Add to cart shows how long it is for this product. For further information see the Ausramp Warranty page.
Minor scratches and blemishes may be visible upon receipt of your item. However, if the item is delivered damaged please contact us immediately.
What is your returns policy?
What is your returns policy?
We know how crucial it is to find the perfect products for your access needs. To ensure you shop confidently, we proudly offer 100-day Free Returns on eligible products.
If you need to return your product, we'll organise and cover the return shipping costs across Australia without any restocking fees or hidden costs.
You'll have the option for a store credit, a full refund, or an exchange when the returned products meet the return criteria:
- The products cannot be used, damaged or modified and must be returned in the original packaging materials.
- Some products, such as almost new, made-to-order, installed, and custom-made products, aren't eligible for return.
- The 100-Day period begins from the day that your order is delivered or picked up.
- Only valid for the original purchaser.
- Only valid for online sales via rampchamp.com.au.
- Refunds, store credits or item swaps apply only to the cost of the products. Installation fees and original shipping costs will not be refunded.
Find our more by visiting our Refund Policy page.
How can I place an order?
How can I place an order?
How to order online: Find a product you'd like to buy on our website and click on the add to cart button. Then, simply follow the instructions on the checkout page. If there were any options or upgrades that you may have missed, one of our customer service staff members will contact you either by email or phone before we process your order.
How to order by phone: Call us on 1300 913 047. Our expert staff will help you select your product based on your individual requirements. We only stock the best brands and have the most competitive prices to ensure that you'll be completely satisfied with every RampChamp.com.au purchase you make. If you feel comfortable, go ahead and place your order online.
How to order by email: Send us an email at hello@rampchamp.com.au and one of our staff members will get back to you as soon as possible with an invoice for your order. Please include the product, any options or upgrades that you might require and your full address for delivery.
Do you have a physical store?
Do you have a physical store?
We do not have a storefront. All items are available for purchase online and are shipped directly from our warehouse or from our partner warehouses directly to our customers Australia wide. If you are within close proximity of any of our partner warehouses, we can arrange for you to pick up the goods by appointment.
Are you an authorised dealer?
Are you an authorised dealer?
Yes, we are. Ramp Champ is 100% authorised to sell the products we advertise on our website. This means that you get the full manufacturer warranty when you buy from RampChamp.com.au.
Do you offer custom ramps?
Do you offer custom ramps?
Yes, we do. Depending on what type of ramp you’re looking for and what state you’re located in, we can offer custom ramps that are built to your specifications. All we need is a few photos, measurements and a sketch of what you want to be made. We offer free quotations so you know exactly what your custom ramp will cost before you decide to buy. Click here to get a custom ramp quotation today.
When will my order ship out?
When will my order ship out?
Each product shows its dispatch time just under the price, for example "In stock, ships next business day" or "Made to order, ships within 3-10 business days". As soon as your order ships, we email you the tracking details so you can see when it will arrive.
How long does the delivery take?
How long does the delivery take?
We send all items via registered courier with tracking details so you can see just where your order is at any point in time. This ensures your item is safe and secure from us to you.
Products are sent during normal business hours, Monday to Friday and from dispatch date, we expect most orders to be delivered between 1 and 10 business days, depending on your location and the location of the warehouse. Some brands are shipped directly from our suppliers' warehouses throughout Australia.
See our full shipping policy here.
Can I pick up my order?
Can I pick up my order?
Pickup available. Select at checkout
Some items can be picked up directly from us or from the manufacturer's warehouse. If available when purchasing, on the cart page select "Store Pickup" as an option.
Or, contact our team to see if there's a warehouse near you.
All pickups are by appointment only.
