Heeve 500kg 2.23m x 300mm Curved Non-Folding Aluminium Loading Ramps - Pair
SKU: H0689+H0689
$290 ex GST
- Length2230mm
- Holds500kg/pair
- Made ofAluminium
- 500kg combined loading capacity when used as a pair
- 250kg capacity per ramp for single-ramp motorcycle use
- Curved design reduces the loading angle and top-edge transition
- 2.23m ramp length helps create a smoother incline
- 300mm wide platform supports stable tyre tracking
Pickup availablei
12-month warrantyi
Heeve 500kg 2.23m x 300mm Curved Non-Folding Aluminium Loading Ramp...
Specifications
| Holds | 500kg/pair |
|---|---|
| Made of | Aluminium |
| Brand | Heeve |
| SKU | H0689+H0689 |
| Length | 2230mm |
| Width | 300mm |
| Weight | 13kg |
| Dimensions | Product (L x W): 2230mm x 300mm |
About this product
Aluminium Loading Ramps With Curved, Low-Angle Design for Motorcycle and ATV Loading (Pair)
This pair of curved aluminium loading ramps provides a flexible solution for both two-wheel and four-wheel loading, with a low-angle design that improves control when moving vehicles onto trailers, utes, or vans.
Each ramp can be used individually for motorcycle loading, or combined as a pair for ATV and UTV loading up to 500kg. The curved profile reduces the steep transition at the top, making loading smoother and more stable across a range of vehicles.
Features and Benefits
- 500kg combined loading capacity when used as a pair
- 250kg capacity per ramp for single-ramp motorcycle use
- Curved design reduces the loading angle and top-edge transition
- 2.23m ramp length helps create a smoother incline
- 300mm wide platform supports stable tyre tracking
- Rung-style surface improves grip during loading
- Lightweight aluminium construction for easier handling
- Non-folding design for consistent strength and stability
Flexible Loading for Bikes and Four-Wheel Vehicles
Each ramp can be used on its own for motorcycle loading, or together as a pair for ATV or UTV loading within the combined capacity. This flexibility makes it a practical choice for users who load different vehicles.
Smoother Vehicle Transitions With Curved Design
The curved ramp profile reduces the sharp breakover point at the top of the ramp. This helps protect vehicles from scraping and improves balance when loading onto higher trays or trailers.
Stable Tyre Support With a Wide Platform
With a 300mm wide surface, each ramp provides reliable tyre coverage for both motorcycle and four-wheel loading. The width helps keep wheels aligned and reduces side-to-side movement during loading.
Reliable Grip in Everyday Loading Conditions
The rung-style surface improves traction for tyres and footwear, helping maintain control when loading in dusty, damp, or uneven environments.
Easy Handling Without Added Bulk
Made from aluminium, the ramps are easy to lift, position and store when not in use. The non-folding design maintains structural integrity without unnecessary complexity.
Suitable for Regular Transport Use
These ramps are well-suited to regular loading of motorcycles, ATVs and UTVs for transport, maintenance, or recreational use.
Delivery
Delivery
i
Special orders come in for you on our next shipment, so the arrival date changes. Ask us and we will tell you the current date before you order.
Estimate delivery to your door
An estimate for this item to that suburb, from the same rates checkout uses. You choose the delivery method at checkout.
Finance Options
Finance Options
Four interest-free payments, the first at checkout. Choose PayPal at checkout and pick Pay in 4.
How Pay in 4 works on PayPal
Orders over $10,000Equipment financeBusiness equipment finance through Centrepoint Finance. Talk to their team about your purchase.
Apply with Centrepoint
Request a Quote
Request a Quote
Built Tough, Backed by Warranty
Engineered for Everyday Access
Sustainability at the Core
Reviews
Frequently Asked Questions
Can these ramps be used individually or only as a pair?
Can these ramps be used individually or only as a pair?
Yes. Each ramp can be used on its own for motorcycle loading up to 250kg, or together as a pair for ATV or UTV loading with a combined capacity of 500kg.
What vehicles are these ramps suitable for?
What vehicles are these ramps suitable for?
These ramps are suitable for motorcycles, dirt bikes and trail bikes when used individually. When used as a pair, they can also be used for ATV or UTV loading within the combined capacity rating.
Do the ramps fold for storage?
Do the ramps fold for storage?
No. These are non-folding aluminium ramps. The single-piece design provides consistent strength and stability during loading.
